主要特点(Key features):
1、配置两个伺服电机控制系统与电脑控制、PLC触摸屏显示配合松下光电眼跟踪控制,操作直观方便,可同时生产两条彩印袋。
2、主机采用进口变频器模拟调速、自动供料系统使制袋平稳,封切准确。自动冲床对折装置、输送带送袋功能,易于收集。
3、摇摆式出料系统,配合袋底整型设计,集袋整齐,夹取冲孔位置准确。
4、切刀采用电流独立加温,高精度控温仪自动控温,操作方便,控温准确。
5、全机采用IC电子迴路自动控制,插座式设计,换装容易;并具有无料、断料、堵料停机功能。
6、我公司凭借多年在塑料机械行业内领先技术,在研发中取得了突破性的进展,打造了新一代的高速制袋机、冲口机,欢迎新老客户前来参观试机。
1. Equipped with two servo motor control systems and computer control, PLC touch screen display with Panasonic photoelectric eye tracking control, intuitive and convenient operation, can produce two color printing bags at the same time.
2. The host adopts imported inverter to simulate speed regulation and automatic feeding system to make the bag making stable and accurate sealing and cutting. Automatic punch folding device, conveyor belt bag feeding function, easy to collect.
3. Swing discharging system, with the bottom of the bag shaping design, the bag collection is neat, and the clamping and punching position is accurate.
4. The cutter is heated independently by current, and the high-precision thermostat automatically controls the temperature, which is convenient to operate and accurate in temperature control.
5. The whole machine adopts IC electronic loop automatic control, socket design, easy to change; And it has the functions of no material, material breaking, and material blocking.
6. With many years of leading technology in the plastic machinery industry, our company has made breakthroughs in research and development, and has created a new generation of high-speed bag-making machine and punching machine.
主要技术参数(Main technical parameters):
型号 | 400×2 | 450×2 | 500×2 |
制袋宽度 | 200-350mm×2 | 200-400mm×2 | 200-450mm×2 |
制袋长度 | 320-650mm×2 | 320-650mm×2 | 320-650mm×2 |
制袋厚度 | 0.005-0.05mm | 0.005-0.05mm | 0.005-0.05mm |
制袋速度 | 250pcs/min×2 | 250pcs/min×2 | 250pcs/min×2 |
空气压力 | 8HP | 10HP | 12HP |
总功率 | 14kw | 16kw | 18kw |
电压 | 380V50Hz | 380V50Hz | 380V50Hz |
机器重量 | 2000kg | 2200kg | 2500kg |
外形尺寸 | 6500×1400×1800mm | 6500×1400×1800mm | 6500×1400×1800mm |
