一、特点Characteristic
1、成品无残存溶剂,生产无污染排放问题,节省能源,占地面积小。
2、复合的过程湿固反应,不可逆,粘合牢固耐水洗牢度好。
3、粘性强,用胶量省,节省成本。
4、复合过程联动控制,质轻柔软,手感好。
5、热源为油热,加热快,热量均匀。
6、熔胶系统独立出来,55加仑压盘式熔胶机,方便,速度快。
7、网纹上胶转移,立体感强。
8、机台人性化设计,节省操作人员。
1. There is no residual solvent in the finished product, no pollution emission problem in production,
energy saving, and small footprint.
2. The process of compounding is moist-solid reaction, irreversible, firm bonding, and good washing
fastness.
3. Strong viscosity, saving glue and saving costs.
4. Composite process linkage control, light and soft, good hand feel.
5. The heat source is oil heat, which heats quickly and the heat is uniform.
6. The glue melting system is independent, and the 55 gallon pressure plate melter is convenient and
fast.
7. Mesh glue transfer, strong three-dimensional effect.
8. The humanized design of the machine saves operators.
二、主要技术参数MainTechnica Parameter
种类 | 贴合机 | 重量 | 3500 |
驱动形式 | 电动 | 机台尺寸 | 7500×3400×2400mm |
用途 | 无纺布、皮革、海绵 | 工作宽度 | 1830mm |
自动化程度 | 全自动 | 工作速度 | 0-40码/分钟 |
功率 | 380(Kw) |
